Wires are metal strands that carry electricity. These electrical conductors are essential to all electrical equipment. Ground wires help limit the danger of electrical overload and fires by channeling surplus current during a short circuit or other malfunction.
The circuit's grounding/earthing wires are the green wires. Their principal function is to ground an electrical circuit and provide a path to ground a circuit's electric current if a live wire inside the structure comes into contact with metal from another conductive substance.
Key Features:
Longest, lasting, and durable wire
Exceeds the criteria of UL 1426, ABYC, and the United States Coast Guard Charter boat (CFR Title 46)
Built with quality vinyl insulation rated at 600V, 105°C dry, and 75°C wet
Saltwater, battery acid, oil, gasoline, heat, abrasion, and ultraviolet radiation resistance
Tinned copper stranding of the highest grade (Type 3)
Protects against corrosion and electrolysis to the greatest extent possible
Specifications:
Brand: Ancor
SKU: 1-102310
UPC: 091887103465
Weight: 1.50 lbs
Color: Green
Length: 100'
Nominal O.D.:1/8" (3.2mm)
Wt./1000': 16 lbs. (7.3 kg)
Stranding: 26 of 30 AWG
Cir. Mil Area: 2600
Square mm: 1.31
Ohms/1000': 4
Manufacturer Part Number (MPN): 102310
Replaces Products: 639-102310, 91887103465
| Nominal O.D. | 1/8" (3.2mm) |
| Wt./1000' | 16 lbs. (7.3 kg) |
| Stranding | 26 of 30 AWG |
| Cir. Mil Area | 2600 |
| Square mm | 1.31 |
| Ohms/1000' | 4 |
