For the DP, 290-DP, and 280 DP Sterndrives, this is the J-type Duoprop set of propellers. When both the inner and outer props need to be replaced, the new J series is designed to replace the A and B series. The unique blade shape and high propeller diameter of Volvo Penta Duoprop 21924265 J5 SET ensure maximum efficiency while operating quietly and smoothly. The propellers are stronger and more durable than standard die-cast propellers because of a specific high-strength aluminum alloy and squeeze casting method. Excellent corrosion protection is provided by four layers of paint. If your current props are heavily pitted, bent, or have worn bushings, it's time to replace them before they fail. Water could enter the lower gearcase through the drive shaft prop seals if the prop is bent.

Key Features:

• Blade geometry is patented, and the active propeller diameter is huge.

• Aluminum alloy with high strength and durability.

• Anti-corrosion properties are outstanding.

• The front propeller has three blades, and the back propeller has four blades.

• Ideal replacement for type A and type B propellers.

Note: In engines with more than 240 horsepower or capable of speeds more than 38 knots, always utilize type C stainless steel propellers (45 mph).

• A Series numbering is almost equivalent to J-Series numbering, i.e. A5 = J5.

• B Series numbering (approximately) correlates to one size larger J-Series numbering, e.g. B5 = J6.

• The same propeller cone, propeller nuts, and washers are used as in the A and B series.

Note: On the same drive, do not mix J-Series with the A or B series. Only utilize the same propeller type on both drives for twin applications.

Specifications:

• SKU: 21924265

• Weight: 19.00 LBS

• Material: Aluminum

• No. of Blades: 3 and 4

• Rotation: Left-hand and right-hand

• Position: Set

• Duoprop Type: J5

Volvo Penta Exploded view / schematic Duoprop Propeller, Aluminum, J Series

This product replaces:

J5S, J5
